4K DVI Fiber Optic Extender , 4096x2160p@30hz , 10G bandwidth ,edid , rs232, LC
DVI-D Single Link RS232 transmitter over fiber, 2km
-
DVI-D Single Link (18+1) for resolutions up to 1920x1200@60HZ
-
Gold plated precision mating contacts, EMI protection, low attenuation
-
DVI-D (18+1) male to LC female, full metal housing
-
Zero frame delay delay and compression free transmission
- description
DVI Fiber Optic Extender , 4096x2160p@30hz , KVM, 4 channels of USB2.0 ,Audio,bilateral rs232, LC
DVI-D Single Link RS232 transmitter over fiber, 2kmTransmits a DVI-D Single Link and USB 2.0 signal up to 2km - with RS232 options
Description
Delivers DVI-D andRS232 signals using OM3 LC duplex optical fibe
Extends DVI-D and RS232 signals using duplex fiber optics
DVI-D Single Link compatible, supports resolutions up to 1920x1200p
The Single Link DVI-D Fiber Extender delivers single link DVI-D signals with resolutions up to 1920x1200 without loss of quality at distances up to2000m using a standard OM3 LC duplex fiber . In addition .
.
.
.
.
-
SPECIFICATIONS:
OperatingTemperatureRange
-5 to +35℃(+23 to +95℉)
OperatingHumidityRange
5 to 90%RH (No Condensation)
Video Input(Transmitter)
1xHDMI Type A, 19-pin, female
Video Output(Receiver)
1xHDMI Type A, 19-pin, female
Link(Transmitter/ Receiver)
1m~60Kmsingle / Multimode single / Duplex fiber optical cable
Module type required①
SFP Type, Single / Multi mode ,Single / Duplex fiber (optional)
Video Format
4K@60Hz YUV 4:2:0, 1080P@60Hz, 1080i, 720P, 576P, 480P
Audio Format
Support LPCM 7.1, Dolby True HD, DTS-HD Master Audio .
HDCP Input
HDCP 2.2, HDCP 1.4
HDCP Output
HDCP 1.4
Power consumption
Transmitter: 3watts(Maximum)
Receive: 3watts(Maximum)
Dimension (L×W×H)
Transmitter: 96*100*25mm
Receive: 96*100*25mm
Net Weight
475g(Pair)
.
-
