Mini 4k 1 Pair RJ45 Port HDMI Extender HDMI Extension to 30m CAT 5e / 6 UTP LAN Ethernet Cable for HDTV HDPC
4K/30HZ up to 150m, 1080p up to 100m via CAT cable
-
Inputs: HDMI, 3.5mm jack for IR signals
-
CAT5E/6 OUT: Network cable output port
-
HDMI OUT: HDMI output port
-
Up to 200m HDMI1.4 extension for home theaters
- description
Mini 4k 1 Pair RJ45 Port HDMI Extender HDMI Extension to 30m CAT 5e / 6 UTP LAN Ethernet Cable for HDTV HDPC
Features.-One pair as fully functional module, no setup required
-Cat-5e/6 cable can replace HDMI cable for long distance transmission
-Transmits 1080p over distances up to 30 meters using CAT-6 cables
-Compact size
- Up to 1.65Gbps signaling rate with 1080p display support
-HDMI Dual-Port Network Cable Extender over Cat 5e/6
Specifications.
Material: Hard plastic
Suitable for Cat-5e/6
Color: Blue
Plug-and-play, hot-swappable support.
Support 3D 1080P HDMI1.4 resolution, 4k*2k
Support HDCP1.1/1.2
Support resolution: 480i/p, 576i/p, 720p, 1080i/p, 1920x1200, 4k*2k
Translated with www.DeepL.com/Translator (free version)
-
SPECIFICATIONS:
OperatingTemperatureRange
-5 to +35℃(+23 to +95℉)
OperatingHumidityRange
5 to 90%RH (No Condensation)
Video Input(Transmitter)
1xHDMI Type A, 19-pin, female
Video Output(Receiver)
1xHDMI Type A, 19-pin, female
Link(Transmitter/ Receiver)
1m~60Kmsingle / Multimode single / Duplex fiber optical cable
Module type required①
SFP Type, Single / Multi mode ,Single / Duplex fiber (optional)
Video Format
4K@60Hz YUV 4:2:0, 1080P@60Hz, 1080i, 720P, 576P, 480P
Audio Format
Support LPCM 7.1, Dolby True HD, DTS-HD Master Audio .
HDCP Input
HDCP 2.2, HDCP 1.4
HDCP Output
HDCP 1.4
Power consumption
Transmitter: 3watts(Maximum)
Receive: 3watts(Maximum)
Dimension (L×W×H)
Transmitter: 96*100*25mm
Receive: 96*100*25mm
Net Weight
475g(Pair)
.
