DisplayPort 1.4 aoc fiber extend cable 8k2k@60hz.

  • DP version 1.4 - 32.4Gbps for resolutions up to 8K UltraHD-2 60Hz

  • DP male to DP male, full metal housing


  • Hybrid cable - fiber for A/V; copper for power & data,

  • Gold-plated precision mating contacts

  • description

  •  DisplayPort 1.4 aoc fiber extend cable 8k2k@60hz

  • DP version 1.4 - 32.4Gbps for resolutions up to 8K UltraHD-2 60Hz
    Gold-plated precision mating contacts, EMI protection, low attenuation
    DP male to DP male, full metal housing
    Hybrid cable - fiber for A/V; copper for power & data,
    AOC technology - no external power supply needed

    The FiberX Active Optical DisplayPort 1.4 cable FX-I250 transmits uncompressed audio and video signals up to 8K@60Hz over distances up to 100m.

    This compact cable is designed for professional applications. User-friendly through simple plug-and-play, it offers full bandwidth of max. 32.4Gbps (HBR3) with absolute 24/7 reliability. The cable is made of fiber optics and copper cores. It is lightweight, flexible and additionally features an unusually tight bend radius of 48mm. With its advanced optical engine, the hybrid cable offers full DisplayPort signal integrity and supports transparent EDID, HDCP (up to v2.2) and DPCP - at zero frame delay, latency-free and without compression (DSC v1.2 is supported). The cable also supports Multi Stream Transport (MST) for cascading multiple displays with just a single cable or via MST hub. For the user, it gives the impression of using a short, high-quality copper cable. Simply connect and the full capacity is available.
    It combine the best of copper and fiber technology

    This series products are the ideal solution for transmitting video and audio signals over long distances and at a maximum of 32.4Gbps using AOC hybrid fiber.
    In doing so, they prevent various limitations that can occur with fiber-only systems.
    The "integrated" AOC fiber optic DisplayPort 1.4 hybrid cable from the FiberX series enables lossless and uncompressed signal transmission of up to 32.4Gbps.
    Thus, it is able to transmit content with a resolution of 8K@60Hz, i.e. UltraHD-II with 60fps.
    The maximum range of this hybrid cable, consisting of fiber and copper strands, is 100 meters - completely lossless and with full EDID and HDCP (up to v2.2) and DPCP support.
    With supported MST (Multi Stream Transport) technology, multiple independent video streams can be distributed over a single DisplayPort output. Thus, multiple monitors with MST support can be cascaded, i.e. connected "in series". Alternatively, a so-called MST hub (also available here) can be used.
    These "integrated" variants even additionally transmit a digital audio signal thanks to the latest chipset.
    The cable also has a minimum bending radius of only 48mm.

    Pre-assembled lengths
    The FX-I250 series is available in lengths from 10m up to 100m, with pre-assembled DisplayPort connectors on both sides.

    Please note
    Do not connect the cable upside down - the ends are clearly marked. Successful connection with a DisplayPort adapter cannot be guaranteed.

    For professional applications and installations
    All FiberX products are manufactured exclusively in state-of-the-art manufacturing facilities and are 100% tested prior to shipment. During the manufacturing process, products undergo more than ten quality tests, making them the most reliable choice on the market.
    Quality and performance:
    - Active optical fiber transmission with 32.4 Gbps bandwidth
    - 8.1 Gbps / lane (HBR3) connection rate
    - Resolutions up to 8K@60Hz 4:4:4 or 4K@144Hz (8bit) and 4K@120Hz (10bit)
    - DisplayPort 1.4 compatible
    - HDCP up to v2.2 compatible
    - DSC (Display Stream Compression) version 1.2
    - Supports transparent EDID
    - Supports MST (Multi Stream Transport) technology
    - Zero Frame Delay, no latency, no compression (except DSC supported monitor)
    - Extremely lightweight hybrid construction, compact design, extra tight bend radius 48mm with 4.8mm outer diameter
    - Kevlar reinforced jacket
    - Supports all DisplayPort audio formats
    - Easy plug-and-play installation
    - Metal housing for optimal EMI protection





      -5 to +35℃(+23 to +95℉)


      5 to 90%RH (No Condensation)

      Video Input(Transmitter)



      1xHDMI Type A, 19-pin, female

      Video Output(Receiver)

      1xHDMI Type A, 19-pin, female

      Link(Transmitter/ Receiver)

      1m~60Kmsingle / Multimode single / Duplex fiber optical cable

      Module type required

      SFP Type, Single / Multi mode ,Single / Duplex fiber (optional)

      Video Format

      4K@60Hz YUV 4:2:0, 1080P@60Hz, 1080i, 720P, 576P, 480P

      Audio Format

      Support LPCM 7.1, Dolby  True HD, DTS-HD Master Audio .


      HDCP Input

      HDCP 2.2, HDCP 1.4

      HDCP Output

      HDCP 1.4

      Power consumption

      Transmitter: 3watts(Maximum)

      Receive: 3watts(Maximum)

      Dimension (L×W×H)

      Transmitter: 96*100*25mm

      Receive: 96*100*25mm

      Net Weight
