16 bays HD3G SDI Fiber Optic Extender rack-mountable enclosure

16 bays HD3G SDI Fiber Optic Extender rack-mountable enclosure

Can accommodate up to 16 modules
Space-saving design with a compact, 3U high, rack-mountable enclosure
Buffered 3G-SDI/HD-SDI/SDI loop-through input
10km single mode fiber (SM)
HDMI output: 1 x HDMI type A

description

16 bays HD3G SDI Fiber Optic Extender rack-mountable enclosure

Modular housing for fiber optic extender
Main features
Can accommodate up to 16 modules
Space-saving design with a compact, 3U high, rack-mountable enclosure
Modular, field upgradeable and hot-swappable design
Optional redundant power supply
Hot-swappable power supplies
Highly effective temperature management

Modular housing for fiber optic extender
Main features
Can accommodate up to eight dual modules
Space-saving design with a compact, 3U high, rack-mountable enclosure
Modular, field upgradeable and hot-swappable design
Optional redundant power supply
Hot-swappable power supplies
Highly effective temperature management

it is a rack-mountable enclosure for a large module selection of fiber optic as well as twisted pair AV transmitters and receivers. it allows multiple transmitters and receivers to be mounted side-by-side and powered, simplifying the integration of large rack-mounted systems. It also offers an optional redundant, hot-swappable power supply with temperature management to optimize the round-the-clock operational reliability required. The modular hot-swap design allows modules to be replaced or upgraded in the field at any time without having to power down the system.

The highly effective temperature management provides optimal cooling and very high reliability through airflows directed to each module individually. Air flows from the side of the unit to each module slot, eliminating the need for an air gap above or below the chassis and saving valuable rack space. The modules are designed to channel air from the rear of the enclosure for optimal cooling in each bay. A front panel LED provides status warning of overheating.

Real-time status indicators on the front panel provide instant feedback on power status, communications, and alarm notification for each of the 16 bays. The front panel configuration port allows communication with each module bay for configuration and convenient setup of fiber optic extenders.

SPECIFICATIONS:

OperatingTemperatureRange	-5 to +35℃(+23 to +95℉)
OperatingHumidityRange	5 to 90%RH (No Condensation)
Video Input(Transmitter)	1xHDMI Type A, 19-pin, female
Video Output(Receiver)	1xHDMI Type A, 19-pin, female
Link(Transmitter/ Receiver)	1m~60Kmsingle / Multimode single / Duplex fiber optical cable
Module type required^①	SFP Type, Single / Multi mode ,Single / Duplex fiber (optional)
Video Format	4K@60Hz YUV 4:2:0, 1080P@60Hz, 1080i, 720P, 576P, 480P
Audio Format	Support LPCM 7.1, Dolby True HD, DTS-HD Master Audio .
HDCP Input	HDCP 2.2, HDCP 1.4
HDCP Output	HDCP 1.4
Power consumption	Transmitter: 3watts(Maximum) Receive: 3watts(Maximum)
Dimension (L×W×H)	Transmitter: 9610025mm Receive: 9610025mm
Net Weight	475g(Pair)
