HD 3G SDI Fiber Optic Extender with reverse rs485, loop out, single fiber fc

HD 3G SDI Fiber Optic Extender with reverse rs485, loop out, single fiber fc.

signal is matched and re-synchronized prior to fiber optic transmissio
transmitter features a re-synchronized SDI loop through
Fiber optic transmission : 300 m (MM)
10km single mode fiber (SM)
HDMI output: 1 x HDMI type A

description

HD 3G SDI Fiber Optic Extender with reverse rs485, loop out, single fiber fc

This device is a mini Fiber Optic Transport unit that is used and extra loop out SDI connector on the transmitter for monitoring and for additional inspection. The matching receiver uses the same technology as the transmitter so that you can actually have 2 SDI outputs on the receiving end of the Fiber. This allows easy access to redistribute primary from a Fiber Cable that needs to be split for two SDI outputs.

It allows you to transmit in HD or SD-SDI as per SMPTE 424M-2006, 292 and 259, with or without embedded audio and data over single mode or multimode fiber. The signals are equalized and re-synchronized prior to fiber optic transmission. The transmitter has one re-synchronized and equalized SDI path and the receiver has two re-synchronized and equalized SDI outputs. Requires the transmitter and the receiver.

This Series is immune to pathological signals throughout the entire link budget and operating temperature range.

This Model supports single mode fiber up to 20 km and has FC connector.

Features
The signal is matched and re-synchronized prior to fiber optic transmission
The transmitter features a re-synchronized SDI loop through
The receiver features two re-synchronized SDI outputs
3G SDI model available
Immunity to pathological patterns over the entire link budget and operatingtemperature range
Compatible with SMPTE 259M-2006,292-2006, (424M-2006, 297-2006 - Optional depending on model)
Supports transmission of SMPTE305M-2005, 310M-2004, 344M-2000, 344M-2000, DVB-ASI
Supports both Single Mode and Multimode ( 62.5 u & 50u) fiber types
Supports HD/SD-SDI with embedded audio and data orwithout
15 dB Optical Link Budget @ 1.5 Gbps and 2.97 Gbps for 3G SDI Model
Wide operating temperature range:-10° C to +50° C

SPECIFICATIONS:

OperatingTemperatureRange	-5 to +35℃(+23 to +95℉)
OperatingHumidityRange	5 to 90%RH (No Condensation)
Video Input(Transmitter)	1xHDMI Type A, 19-pin, female
Video Output(Receiver)	1xHDMI Type A, 19-pin, female
Link(Transmitter/ Receiver)	1m~60Kmsingle / Multimode single / Duplex fiber optical cable
Module type required^①	SFP Type, Single / Multi mode ,Single / Duplex fiber (optional)
Video Format	4K@60Hz YUV 4:2:0, 1080P@60Hz, 1080i, 720P, 576P, 480P
Audio Format	Support LPCM 7.1, Dolby True HD, DTS-HD Master Audio .
HDCP Input	HDCP 2.2, HDCP 1.4
HDCP Output	HDCP 1.4
Power consumption	Transmitter: 3watts(Maximum) Receive: 3watts(Maximum)
Dimension (L×W×H)	Transmitter: 9610025mm Receive: 9610025mm
Net Weight	475g(Pair)
