HD3G SDI Fiber Extender with bilateral audio and rs232, Loop out LC single fiber

HD3G SDI Fiber Extender with bilateral audio and rs232, Loop out LC single fiber

HD3G SDI Fiber Extender with bilateral audio and rs232,
Loop out LC single fiber
Fiber optic transmission : 300 m (MM)
10km single mode fiber (SM)
HDMI output: 1 x HDMI type A

description

HD3G SDI Fiber Extender with bilateral audio and rs232, Loop out LC single fiberernet, bilateral rs232 , FC single fiber

This range of video extenders is available with a choice of SFP fiber adapters to extend SDI camera sources or any other SDI source in up to 4K resolution over distances of up to 300m on OM3 fiber and up to 40km on single mode fiber.

The receiver has four BNC connectors on the front for SDI outputs and then a BNC for sync input. The rear has a slot for an SFP+ module and a screw terminal for the RS232 interface. The top of the unit has a mini-USB socket for firmware update and monitoring as well as LEDs for each SDI, 'Sync' and 'Pwr' connection. One side has the coaxial power supply socket

The transmitter and receiver of this version are each supplied with a 10G SFP+ transmitter/receiver with LC connectors for use with OM3 multimode fiber, for a range of 300m, or OM4, for a range of 400m.

SPECIFICATIONS:

OperatingTemperatureRange	-5 to +35℃(+23 to +95℉)
OperatingHumidityRange	5 to 90%RH (No Condensation)
Video Input(Transmitter)	1xHDMI Type A, 19-pin, female
Video Output(Receiver)	1xHDMI Type A, 19-pin, female
Link(Transmitter/ Receiver)	1m~60Kmsingle / Multimode single / Duplex fiber optical cable
Module type required^①	SFP Type, Single / Multi mode ,Single / Duplex fiber (optional)
Video Format	4K@60Hz YUV 4:2:0, 1080P@60Hz, 1080i, 720P, 576P, 480P
Audio Format	Support LPCM 7.1, Dolby True HD, DTS-HD Master Audio .
HDCP Input	HDCP 2.2, HDCP 1.4
HDCP Output	HDCP 1.4
Power consumption	Transmitter: 3watts(Maximum) Receive: 3watts(Maximum)
Dimension (L×W×H)	Transmitter: 9610025mm Receive: 9610025mm
Net Weight	475g(Pair)
