4k2k@60hz(4:4:4) 18G HDMIUncompressed Extender

  • RGB, YCbCr 4:4:4, YCbCr 4:2:2 and YCbCr 4:2:0

  • Bandwidth up to 600 MHz (18 Gbps)

  • Supports HDCP 2.2

  • Up to 48-bit color depth

  • via MM Fiber Optics ,mpo ,300m

  • description

  • 4k2k@60hz(4:4:4) 18G HDMIUncompressed Extender via MM Fiber Optics ,mpo ,300m

  • 4K60 HDMI 2.0 over Fiber Optic Extension
    This Fiber Extender provides remote 4Kx2K UHD HDMI monitor) over a duplex MM fiber cable (up to 300meters).

    Features
    Signal transmission via duplex MM mpo fiber optic cable
    Extends the signal paths of HDCP-encrypted video signals by up to 300 meters
    Extends signal paths of unencrypted video signals up to 300 meters
    Supports Ultra-HD 4Kx2K resolutions up to 3840x2160 and 4096x2160 @60Hz YUV 4:4:4 and HDTV resolutions up to 1080p @144Hz
    Supported HDMI functionalities:
    HDMI 2.0
    RGB, YCbCr 4:4:4, YCbCr 4:2:2 and YCbCr 4:2:0
    Dolby TrueHD, LPCM 7.1, DTS-HD Master Audio, ATMOS, and DTS:X
    Up to 48-bit color depth
    Bandwidth up to 600 MHz (18 Gbps)
    3D
    HDR
    HDCP 2.2 compliant
    Integrated mounting brackets for easy surface mounting or wall mounting.

    •


      SPECIFICATIONS:

      OperatingTemperatureRange

      -5 to +35℃(+23 to +95℉)

      OperatingHumidityRange

      5 to 90%RH (No Condensation)

      Video Input(Transmitter)





      1xHDMI Type A, 19-pin, female

      Video Output(Receiver)

      1xHDMI Type A, 19-pin, female

      Link(Transmitter/ Receiver)

      1m~60Kmsingle / Multimode single / Duplex fiber optical cable

      Module type required

      SFP Type, Single / Multi mode ,Single / Duplex fiber (optional)

      Video Format

      4K@60Hz YUV 4:2:0, 1080P@60Hz, 1080i, 720P, 576P, 480P

      Audio Format

      Support LPCM 7.1, Dolby  True HD, DTS-HD Master Audio .



      HDCP Input

      HDCP 2.2, HDCP 1.4

      HDCP Output

      HDCP 1.4

      Power consumption

      Transmitter: 3watts(Maximum)

      Receive: 3watts(Maximum)

      Dimension (L×W×H)

      Transmitter: 96*100*25mm

      Receive: 96*100*25mm

      Net Weight

      475g(Pair)

     .
