HDMI DVI Solutions >
< hdmi fiber Optic extender >
hdmi 1.4 4K@30hz single fiber Extenderr with bidirectional audio/rs232 , fc or sc

hdmi 1.4 4K@30hz single fiber ( fc or sc)

with bidirectional audio/rs232
4K video up to 4096x2160 at 30 Hz /p>
data rates up to 10 Gbps,
enables very long transmission distances
singlemode fiber at 1310 nm

description

hdmi 1.4 4K@30hz single fiber Extenderr with bidirectional audio/rs232 , fc or sc

Supports mathematically lossless 4K video up to 4096x2160 at 30 Hz .
Supports HDMI 1.4 specifications including data rates up to 10 Gbps,.

It is a compact fiber-optic receiver for transmitting HDMI video signals with embedded audio over long fiber-optic distances. Designed for exceptional high-definition images, the receiver uses Extron's all-digital technology for mathematically lossless transmission of 4K/30 images over a fiber optic cable. Designed specifically for AV systems, low-profile chassis can be installed inconspicuously.

It supports singlemode fiber at 1310 nm and enables very long transmission distances. Single-mode fiber can be used in very large facilities such as airports and stadiums, as well as to provide connectivity over very long distances, such as between buildings in a university. Because content sent over fiber is secure from outside access, applications using fiber are especially popular in government, military, and medical settings. The receiver has connections for industry-standard SC/FC connectors.

SPECIFICATIONS:

OperatingTemperatureRange	-5 to +35℃(+23 to +95℉)
OperatingHumidityRange	5 to 90%RH (No Condensation)
Video Input(Transmitter)	1xHDMI Type A, 19-pin, female
Video Output(Receiver)	1xHDMI Type A, 19-pin, female
Link(Transmitter/ Receiver)	1m~60Kmsingle / Multimode single / Duplex fiber optical cable
Module type required^①	SFP Type, Single / Multi mode ,Single / Duplex fiber (optional)
Video Format	4K@60Hz YUV 4:2:0, 1080P@60Hz, 1080i, 720P, 576P, 480P
Audio Format	Support LPCM 7.1, Dolby True HD, DTS-HD Master Audio .
HDCP Input	HDCP 2.2, HDCP 1.4
HDCP Output	HDCP 1.4
Power consumption	Transmitter: 3watts(Maximum) Receive: 3watts(Maximum)
Dimension (L×W×H)	Transmitter: 9610025mm Receive: 9610025mm
Net Weight	475g(Pair)
