2x4 4K 60Hz 4:4:4 18GB HDMI splitter / switches

  • HDMI splitter/Switch supports HDMI video resolutions up to 4K @60Hz

  • supports HDCP2.2 HDMI input and output signals

  • comprehensive EDID management - Multiple built-in EDID settings

  • 1x2 4K60 HDMI splitter /Switch

  •   HDMI  extension for home theaters

  • description

  •   2x4 4K 60Hz 4:4:4 18GB HDMI splitter / switches

  • 2x4 4K 60Hz 4:4:4 18GB HDMI splitter / switches incl. audio extraction .

    For resolutions up to 4K@60Hz, 4:4:4 with 18Gbps incl. HDR formats like Dolby Vision
    Features RCA (analog) and Toslink (S/PDIF optical, digital) audio outputs
    Includes a 4K to 1080p down-scaler as well as signal equalizer for longer HDMI runs
    Input support for HDCP 2.2, outputs with support for active or passive HDCP mode
    , EDID management





      -5 to +35℃(+23 to +95℉)


      5 to 90%RH (No Condensation)

      Video Input(Transmitter)



      1xHDMI Type A, 19-pin, female

      Video Output(Receiver)

      1xHDMI Type A, 19-pin, female

      Link(Transmitter/ Receiver)

      1m~60Kmsingle / Multimode single / Duplex fiber optical cable

      Module type required

      SFP Type, Single / Multi mode ,Single / Duplex fiber (optional)

      Video Format

      4K@60Hz YUV 4:2:0, 1080P@60Hz, 1080i, 720P, 576P, 480P

      Audio Format

      Support LPCM 7.1, Dolby  True HD, DTS-HD Master Audio .


      HDCP Input

      HDCP 2.2, HDCP 1.4

      HDCP Output

      HDCP 1.4

      Power consumption

      Transmitter: 3watts(Maximum)

      Receive: 3watts(Maximum)

      Dimension (L×W×H)

      Transmitter: 96*100*25mm

      Receive: 96*100*25mm

      Net Weight
