4K@ 30Hz HDMI1.4 wireless extender kit - 200 m
HDMI1.4 wireless extender kit - 200 m
-
Maximum possible transmission distance: 200 m
-
HDMI loop output at the transmitter
-
Features of the 10G 4K HDMI 1.4
-
Up to 200m HDMI1.4 extension for home theaters
- description
4K@ 30Hz HDMI1.4 wireless extender kit - 200 m
Product Description
This Wireless HDMI Extender Kit - 200m - 1080p - HDMI over wireless extender - LPCM 5.1 / 7.1 audio. Type: AV transmitter & receiver, Maximum resolution: 4K@ 30H, Maximum possible transmission distance: 200 m. Transmission technology: Wireless . Working voltage: 5 V, Output current: 2 A. Width: 64 mm .
Features:
Type: AV Transmitter & Receiver
Maximum resolution: 1920 x 1080 pixels
Maximum possible transmission distance: 200 m
LED indicators: Yes
Product Color: Black
Connections and interfaces:
Transmission technology: Wireless
HDMI In: 1
Number of HDMI-out: 1
Number of USB ports: 2
Remote control (IR) output: 1
DC connector: Yes
Operating conditions:
Operating temperature range: 0 - 40 °C
Temperature range during storage: -20 - 80 °C
Humidity in operation: 25 - 60.
-
SPECIFICATIONS:
OperatingTemperatureRange
-5 to +35℃(+23 to +95℉)
OperatingHumidityRange
5 to 90%RH (No Condensation)
Video Input(Transmitter)
1xHDMI Type A, 19-pin, female
Video Output(Receiver)
1xHDMI Type A, 19-pin, female
Link(Transmitter/ Receiver)
1m~60Kmsingle / Multimode single / Duplex fiber optical cable
Module type required①
SFP Type, Single / Multi mode ,Single / Duplex fiber (optional)
Video Format
4K@60Hz YUV 4:2:0, 1080P@60Hz, 1080i, 720P, 576P, 480P
Audio Format
Support LPCM 7.1, Dolby True HD, DTS-HD Master Audio .
HDCP Input
HDCP 2.2, HDCP 1.4
HDCP Output
HDCP 1.4
Power consumption
Transmitter: 3watts(Maximum)
Receive: 3watts(Maximum)
Dimension (L×W×H)
Transmitter: 96*100*25mm
Receive: 96*100*25mm
Net Weight
475g(Pair)
.
