4K@30Hz HDMI1.4 Splitter 2 to 8 HDMI Switch Splitter 2 in 8 Out
Switching memory function&2 switching methods
-
supports HDCP2.2 HDMI input and output signals
-
comprehensive EDID management - Multiple built-in EDID settings
-
Switching memory function&2 switching methods
-
HDMI extension for home theaters
- description
4K@30Hz HDMI1.4 Splitter 2 to 8 HDMI Switch Splitter 2 in 8 Out
Support resolution up to Ultra HD 4K 30Hz, up to 36 bit/pixel Deep Color
Support LPCM 7.1, Dolby TrueHD, Dolby Digital Plus, and DTS-HD Master Audio
Support EDID mode adjust, compatible with most of the HDMI sources and displays
Support HDMI input/output cable up to 10 meters
With 2 input sources, each of them can be distributed to 8 Ultra HD displays.
Supports resolutions up to Ultra HD 4K 30Hz
Supports up to 36 bit/pixel Deep Color
Supports EDID mode setting, compatible with most HDMI sources and displays.
HDCP 1.4 compliantI
-
SPECIFICATIONS:
OperatingTemperatureRange
-5 to +35℃(+23 to +95℉)
OperatingHumidityRange
5 to 90%RH (No Condensation)
Video Input(Transmitter)
1xHDMI Type A, 19-pin, female
Video Output(Receiver)
1xHDMI Type A, 19-pin, female
Link(Transmitter/ Receiver)
1m~60Kmsingle / Multimode single / Duplex fiber optical cable
Module type required①
SFP Type, Single / Multi mode ,Single / Duplex fiber (optional)
Video Format
4K@60Hz YUV 4:2:0, 1080P@60Hz, 1080i, 720P, 576P, 480P
Audio Format
Support LPCM 7.1, Dolby True HD, DTS-HD Master Audio .
HDCP Input
HDCP 2.2, HDCP 1.4
HDCP Output
HDCP 1.4
Power consumption
Transmitter: 3watts(Maximum)
Receive: 3watts(Maximum)
Dimension (L×W×H)
Transmitter: 96*100*25mm
Receive: 96*100*25mm
Net Weight
475g(Pair)
.
